- SEAL FOR DIN UNION
- Dimensions
Unit: mm
|
SIZE |
øA |
øB |
H |
|
DN10 |
20.0 |
12.0 |
4.5 |
|
DN15 |
26.0 |
18.0 |
4.5 |
|
DN20 |
33.0 |
23.0 |
4.5 |
|
DN25 |
40.0 |
30.0 |
5.0 |
|
DN32 |
46.0 |
36.0 |
5.0 |
|
DN40 |
52.0 |
42.0 |
5.0 |
|
DN50 |
64.0 |
54.0 |
5.0 |
|
DN65 |
81.0 |
71.0 |
5.0 |
|
DN75 |
88.0 |
78.0 |
5.0 |
|
DN80 |
95.0 |
85.0 |
5.0 |
|
DN100 |
114.0 |
104.0 |
6.0 |
|
DN125 |
142.0 |
130.0 |
7.0 |
|
DN150 |
167.0 |
155.0 |
7.0 |
